Unitech Tools Series
SC-B Series
High-performance thermal imager with 640×512 resolution, 40m laser ranging, 3 focus options (manual/motorized/auto), and IP54 protection.
Branding options: neutral packaging is available. Custom branding is subject to model, quantity and order confirmation.
- ✓ 640×512 high resolution
- ✓ 40m laser ranging
- ✓ 3 focus modes
- ✓ Multiple lens options
- ✓ IP54 protection
- ✓ HDMI output
✓ Certification Documents Available
✓ Warranty Terms Confirmed by Model
✓ Ships Worldwide
✓ Selected Supply Channel
Technical Specifications
| Detector Type | Uncooled FPA, VOX |
| IR Resolution | 640 × 512 |
| Thermal Sensitivity (NETD) | < 40mK (@30°C) |
| Spectral Range | 8 ~ 14 μm |
| Focus Options | Manual / Motorized / Auto |
| Temperature Range | -20°C ~ +150°C / 0°C ~ +410°C |
| Optional Range | +300°C ~ +2000°C |
| Temperature Accuracy | ±2°C or ±2% of readings |
| Laser Ranging | 40 m |
| WiFi / 4G | Supported |
| Battery Life | > 3 hours |
| Weight | 1.23 kg (with battery) |
| Dimensions | 279 × 135 × 147 mm |
| Protection Grade | IP54 |
Applications
- Power line inspection
- Substation maintenance
- Industrial inspection
- Building diagnostics
- R&D
Ready to Order?
Contact us for pricing, bulk discounts, and shipping to your country. We ship to Latin America, Africa, Australia, and worldwide.
